In residential most techs and installers size the suction (vapor) and liquid lines to the stubs on the equipment and in larger built-up systems it is rarely the responsibility of the technician to size the piping.

But what happens if we show up to a job and the lines cannot be (reasonably) replaced and the size is different? or what if the stub on the evaporator coil is a different size than the condenser?

The Factors in Suction Line Sizing

  1. Pressure Drop – Any pressure drop in the suction line due to size, length or fittings results in lower refrigerant density and higher compression ratio at the compressor without a corresponding decrease in evaporator temperature. In other words, you get all the bad stuff like compressor overheating and poor capacity without a lower evaporator operating temperature. This is why pressure drops in the suction line are generally recommended to be less than 3PSI on R22 and 5PSI on R410 but the lower the better.
  2. Oil Carry – When mineral oil was used oil carry was a bigger deal than it is now but manufacturers still design the systems with a minimum suction refrigerant velocity which means that bigger isn’t better. The York / Johnson controls guide says the following

Minimum (suction) velocity of 1000 fpm for vertical lines and 800
fpm for horizontal lines guarantee proper oil return

Equivalent Length

Before we look at an example of a suction line selection chart we must first square on this topic of “equivalent” length. You need to calculate the actual line length and then add-in the equivalent length of fittings (very similar to duct design). By just a quick glance at the chart above you can see the advantage of using long-radius 90’s.

Manufacturers Chart

Now it’s time to look at your manufacturer’s literature to see if a particular suction line size is acceptable. The one above applies to standard Carrier R-410a single-stage heat pumps and comes from the system product data.

Take a look at the 5-ton system at the bottom of the chart. You may have thought that a 3/4″ line set could NEVER be used on a 5-ton but this chart clearly shows that on line sets with equivalent lengths of under 50′ the % of capacity loss will only be 1%. While this isn’t ideal it may be the only economical option in some cases. On the other hand, a 5/8″ suction line on a 3.5 ton is “off the chart” meaning it isn’t acceptable under any conditions.

Either way, our goal is to keep suction line pressure drop to a minimum while maintaining the minimum suction velocity and this is the sweet spot manufacturers are keeping you in with these charts.



While there are various line lift, sizing and trapping guidelines depending on oil and refrigerant type there is one guideline we can all understand easily and remember to apply and this is to slope suction lines towards condensing units / compressors.

Keeping the suction line sloped toward the compressor, especially with long, overhead lines helps to return the oil back which assists with capacity and lubrication resulting in fewer issues.

A good general rule is to slope the suction line 1/2″ per 10′ of horizontal run.

Short and simple but often forgotten.

— Bryan
